[MG] Small Water Chiller for Plastic Blow Machine

Ask Lasest Price
Brand Name :	MGREENBELT
Model Number :	MG-15C(D)
Certification :	CE
Price :	FOB Qingdao $5000~$12000
Delivery Time :	Within 15 working days
Payment Terms :	T/T,D/A,D/P
Supply Ability :	300 Sets/Months

Add to Cart

Product Details
Company Profile

[MG] Small Water Chiller for Plastic Blow Machine

[MG] Small Water Chiller for Plastic Blow Machine

Feature

1).Power supply:3PH-200V/220V/380V/415V-50HZ/60HZ

2).Refrigerant R22/R407c

3).Set temperature range: From -30 to +35°C

4).Cooling capacity: 1HP-671HP (0.8tons-573tons)
5).Compressor type:Screw type,Scroll type

6).Compressor brand: SANYO, COPELAND, DANFOSS, HANBELL.DAIKIN, HITACHI.

Technical Specification

Model	Unit	MG-5C	MG-8C(D)	MG-10C(D)	MG12C(D)	MG15C(D)	MG20C(D)
Nominal cooling capacity	kcal/h	11420	17458	22842	25585	35948	47558
Nominal cooling capacity	KW	13.28	20.3	26.56	29.75	41.8	55.3
Input power	KW	5.69	8.45	10.75	11.82	16.42	20.41
Power supply		3PH-380V-50HZ
Refrigerant	Type	R22 or R407c
Refrigerant	Type of control	Thermostatic expansion valve
Compressor	Type
Compressor	Power(kw)	4.55	3.6*2	4.55*2	9.82	13.72	8.3*2
Condenser	Type
Condenser	Cooling air flow(m3/h)	5000	8000	10000	12000	15000	20000
Evaporator	type
	Chilled fluid flow(m3/h)	2.74	4.2	5.49	6.15	8.63	11.42
	Volume(L)	70	120	200	200	270	350
	Inlet and outlet pipe diameter(inch)	1"	1-1/2"	1-1/2"	2"	2"	2"
Pump	Power(kw)	0.75	0.75	0.75	1.1	1.5	2.25
Pump	Lift(m)	20	22	20	20	20	20
Dimension	Length(mm)	1140	1300	1530	1530	1850	2000
	Width(mm)	560	720	780	780	990	1130
	Heigth(mm)	1040	1310	1430	1430	1680	1720
Weight	kg	175	310	450	530	750	835

Applications

•Plastics (Injection, Blow Molding, Extrusion, Film Extrusion, Thermoforming)
•Paper (Manufacturer, Printing, Card Board, Labels, Plastic Film)
•Mechanical (Welding, Cutting, Profiling, Polishing, Rolling, Grinding)
•Other (Wood, Ceramics, Gold & Silver, Pharmaceutical, Textile)

[MG] Small Water Chiller for Plastic Blow Machine

If any further questions or inquiry please contact with us:

Ms Grace Zhang

Ph:+8618615626360

Skype:mb.gracezhang

Email:mg.chillers at gmail.com

[MG] Small Water Chiller for Plastic Blow Machine
